Timken - Take-Up Mounted Bearings - Shaft Size 17.0mm | UELT203

UELT203 Take-Up Bearing Unit – 17 mm Shaft | Eccentric Locking Collar Upgrade your machinery with the UELT203 Take-Up Bearing Unit, designed for smooth and reliable performance in high-load applications. Built with a 17 mm shaft size and... Read More
Vendor: Timken
SKU: UELT203
$76.13
$76.13
Subtotal: $76.13

On Time, Every Time

Reliable delivery guaranteed.

Secure Payments

Shop with confidence.

100% Happiness Guarantee

Only at Industrial Shed.

UELT203 Take-Up Bearing Unit – 17 mm Shaft | Eccentric Locking Collar

Upgrade your machinery with the UELT203 Take-Up Bearing Unit, designed for smooth and reliable performance in high-load applications. Built with a 17 mm shaft size and a secure eccentric locking collar, this unit offers quick installation and robust locking for rotating equipment. Its take-up housing construction allows for easy belt tension adjustments, making it ideal for conveyor systems and other industrial setups.

Crafted with precision engineering, the UELT203 bearing provides high load capacity, excellent alignment capability, and long-lasting durability under demanding conditions.

Key Features & Benefits:

  • Shaft Size: 17 mm
  • Locking Style: Eccentric Locking Collar
  • Housing Type: Take-Up

Dimensions:

  • Housing Width (A): 32 mm
  • Slot Width (A1): 12 mm
  • Socket Width (A2): 21 mm
  • Total Height (H): 89 mm
  • Pitch Height (H1): 76 mm
  • Height (H2): 51 mm
  • Total Length (L): 94 mm
  • Shaft Length (L1): 61 mm
  • Dimension (L2): 10 mm
  • Slot Length (L3): 51 mm
  • Adjustment Screw Bore (N): 19 mm
  • Opening Width (N1): 16 mm
  • Opening Height (N2): 32 mm
  • Center of Bearing from End (S): 17.1 mm
  • Dimension (B1): 43.7 mm
  • Grease Nipple Size: B-1/4-28UNF

Load Ratings:

  • Static Load Rating: 6,650 N
  • Dynamic Load Rating: 12,800 N
