Timken - Two-Bolt Flanged Mounted Bearings - Eccentric Locking Collar - Shaft Size 65.0mm | UELFL213

UELFL213 Two-Bolt Flange Bearing Unit – 65 mm Shaft | Eccentric Locking Collar Ensure stable and efficient performance in your machinery with the UELFL213 Two-Bolt Flange Bearing Unit, designed for demanding industrial environments. Engineered with a 65 mm... Read More
Vendor: Timken
SKU: UELFL213
$368.48
$368.48
Subtotal: $368.48

On Time, Every Time

Reliable delivery guaranteed.

Secure Payments

Shop with confidence.

100% Happiness Guarantee

Only at Industrial Shed.

UELFL213 Two-Bolt Flange Bearing Unit – 65 mm Shaft | Eccentric Locking Collar

Ensure stable and efficient performance in your machinery with the UELFL213 Two-Bolt Flange Bearing Unit, designed for demanding industrial environments. Engineered with a 65 mm shaft size and an eccentric locking collar, this unit offers reliable shaft retention and alignment under heavy loads and continuous motion.

Built into a rugged two-bolt flange housing, it is easy to install and ensures long-term stability, especially in high-vibration or rotating applications. The bearing offers a dynamic load rating of 57,200 N and a static load rating of 40,100 N, making it ideal for conveyor systems, agricultural equipment, and heavy-duty machinery.

Key Specifications:

  • Shaft Size (d): 65 mm
  • Locking Style: Eccentric Locking Collar
  • Housing Construction: Two-Bolt Flange

Dimensions:

  • Total Length (H): 258 mm
  • Total Height (L): 155 mm
  • Housing Width (A): 50 mm
  • Bolt Hole Spacing (J): 210 mm
  • Bolt Hole Size (N): 23 mm
  • Flange Thickness (A1): 20 mm
  • Center of Bearing from Housing End (A2): 30 mm
  • Center of Bearing from Bearing End (S): 34.1 mm
  • Dimension B1: 85.7 mm
  • Dimension A0: 81.6 mm
  • Bolt Size: M20

Load Ratings:

  • Static Load Rating: 40,100 N
  • Dynamic Load Rating: 57,200 N
