RELN - Storm Drain 1m Complete with Ductile Iron Grate Class C | 003108

RELN - Storm Drain 1m Complete with Ductile Iron Grate Class C | 003108

$98.77
$98.77
Vendor: RELN
SKU: 3108

The RELN Storm Drain 1m Complete with Ductile Iron Grate Class C (003108) is a heavy-duty surface drainage system engineered for demanding trafficable environments. Designed for commercial driveways, industrial areas, and high-traffic residential applications, this drainage system efficiently captures and distributes large...

Read moreRead less

RELN Storm Drain 1m Complete with Ductile Iron Grate Class C | 003108

The RELN Storm Drain 1m Complete with Ductile Iron Grate Class C (003108) is a heavy-duty surface drainage system engineered for demanding trafficable environments. Designed for commercial driveways, industrial areas, and high-traffic residential applications, this drainage system efficiently captures and distributes large volumes of stormwater while delivering superior load-bearing strength.

Featuring a Class C rated ductile iron grate and durable UV stabilised recycled plastic channel construction, this complete 1m drainage system is built for long-term outdoor durability in harsh Australian conditions.

► Key Features

  • Complete 1m heavy-duty drainage system
  • Class C ductile iron grate for high-load trafficable applications
  • Deep 100mm profile efficiently distributes stormwater
  • Suitable for driveways, commercial paving, and industrial areas
  • Interchangeable clip-in grate system for easy installation
  • Hold-down feet help prevent flotation during concrete pours
  • Pipe cut-outs allow connection to 90mm PVC stormwater pipe
  • Made in Australia from UV stabilised recycled plastic

► Technical Specifications

  • Product Type: Complete Surface Drainage System
  • Length: 1m
  • External Width: 121mm
  • Height: 129mm
  • Profile Depth: 100mm
  • Grate Material: Ductile Iron
  • Load Rating: Class C
  • Weight: 10.5kg
  • Channel Material: UV Stabilised Recycled Plastic
  • Pipe Compatibility: 90mm PVC Stormwater Pipe
  • Application: Heavy-duty commercial and residential drainage
  • Brand: RELN
  • Part No.: 003108

► Why Tradies Grab This

Built for demanding outdoor drainage environments where heavy load strength and dependable stormwater performance are critical. Ideal for commercial driveways, industrial zones, and high-traffic residential projects.

► Industrial Shed’s Trade Guarantee – Shop with Confidence

  • Commercial-Grade Quality: Built tough for demanding drainage applications.
  • Fast Dispatch: Get site-ready products delivered quickly Australia-wide.
  • Reliable Performance: Designed for harsh outdoor environments.
  • Real Trade Support: Backed by a team that understands civil and drainage projects.

► Stock won’t last — get yours now at Industrial Shed!

Product weight
22000 g
Material
Ductile Iron
Category
Plumbing & Fluid Handling
Request a freight quote

Confirm delivery costs before you order.

Subtotal: $98.77
Product weight
22000 g
Product size
7

Get a freight quote

Send us your delivery details. Our team will email you a confirmed freight price.

Selected product and quantity

Enter four digits to find suburbs.

Where is it going?

We’ll use this to reply to your freight request.

No payment required. A freight request does not reserve stock, place an order or change your cart.
Product specifications
Category
Plumbing & Fluid Handling
Material
Ductile Iron
Product weight
22000 g
Length
1000 mm
Width
1000 mm
Height
129 mm
Barcode
9319022031086

  • On time, every time

    Delivery across Australia, with tracking sent after dispatch. Ordering a large or heavy item? Ask our team to confirm freight costs and delivery arrangements before you buy.

    Delivery information

  • Secure payments

    Pay through our secure checkout with the card and express payment options available for your order. Review your items, delivery charges and total before confirming payment.

  • 100% happiness guarantee

    Need help after your purchase? Contact our Somerville team with your order number. We can help with product issues and explain your return options, including conditions and exclusions.

    Returns and support
Description

RELN Storm Drain 1m Complete with Ductile Iron Grate Class C | 003108

The RELN Storm Drain 1m Complete with Ductile Iron Grate Class C (003108) is a heavy-duty surface drainage system engineered for demanding trafficable environments. Designed for commercial driveways, industrial areas, and high-traffic residential applications, this drainage system efficiently captures and distributes large volumes of stormwater while delivering superior load-bearing strength.

Featuring a Class C rated ductile iron grate and durable UV stabilised recycled plastic channel construction, this complete 1m drainage system is built for long-term outdoor durability in harsh Australian conditions.

► Key Features

  • Complete 1m heavy-duty drainage system
  • Class C ductile iron grate for high-load trafficable applications
  • Deep 100mm profile efficiently distributes stormwater
  • Suitable for driveways, commercial paving, and industrial areas
  • Interchangeable clip-in grate system for easy installation
  • Hold-down feet help prevent flotation during concrete pours
  • Pipe cut-outs allow connection to 90mm PVC stormwater pipe
  • Made in Australia from UV stabilised recycled plastic

► Technical Specifications

  • Product Type: Complete Surface Drainage System
  • Length: 1m
  • External Width: 121mm
  • Height: 129mm
  • Profile Depth: 100mm
  • Grate Material: Ductile Iron
  • Load Rating: Class C
  • Weight: 10.5kg
  • Channel Material: UV Stabilised Recycled Plastic
  • Pipe Compatibility: 90mm PVC Stormwater Pipe
  • Application: Heavy-duty commercial and residential drainage
  • Brand: RELN
  • Part No.: 003108

► Why Tradies Grab This

Built for demanding outdoor drainage environments where heavy load strength and dependable stormwater performance are critical. Ideal for commercial driveways, industrial zones, and high-traffic residential projects.

► Industrial Shed’s Trade Guarantee – Shop with Confidence

  • Commercial-Grade Quality: Built tough for demanding drainage applications.
  • Fast Dispatch: Get site-ready products delivered quickly Australia-wide.
  • Reliable Performance: Designed for harsh outdoor environments.
  • Real Trade Support: Backed by a team that understands civil and drainage projects.

► Stock won’t last — get yours now at Industrial Shed!
