Bearing NACHI Ball Bearing Shielded

$11.66
$11.66
SKU: 6206-ZZEC3/NACHI

Need a 6206-ZZEC3? This Nachi deep groove ball bearing (30mm ID x 62mm OD x 16mm W) is made to the standard designation, so it drops straight into the original housing with no machining. Stocked at Industrial Shed with trade pricing and...

Read moreRead less

Nachi 6206-ZZEC3 Deep Groove Ball Bearing – 30mm ID x 62mm OD x 16mm W

Need a 6206-ZZEC3? This Nachi deep groove ball bearing (30mm ID x 62mm OD x 16mm W) is made to the standard designation, so it drops straight into the original housing with no machining. Stocked at Industrial Shed with trade pricing and fast Australia-wide dispatch.

► Key Features

  • Metal shielded both sides — low friction for higher speeds, keeps out coarse contamination; supplied greased
  • 6200 light series: the general-purpose workhorse of the metric range
  • C3 (greater than normal) internal clearance — allows for heat and interference fits on motors and fast-running shafts
  • Takes radial load plus moderate thrust load in both directions

► Technical Specifications

  • Part Number: 6206-ZZEC3
  • Bore (ID): 30mm
  • Outside Diameter (OD): 62mm
  • Width: 16mm
  • Type: Single Row Deep Groove Ball Bearing
  • Series: 6200 Series
  • Seal / Shield: Shielded 2 Sides (Metal)
  • Internal Clearance: C3
  • Brand: Nachi

► Typical Applications

Electric motors, pumps, gearboxes, fans and blowers, conveyor pulleys, agricultural implements and workshop machinery.

► Why Tradies Grab This

When a motor or pump starts to growl, this is usually the part that needs replacing. Having the exact designation on the shelf gets the machine back running the same day.

► Industrial Shed’s Trade Guarantee

  • We Stand By Our Gear: if it is not tough enough for the job, we will make it right.
  • Loyalty Matters: trade account pricing for repeat customers.
  • Real Support: talk to our crew — people who work on this gear, not a call centre.
  • Fast Dispatch: stocked lines out the door quickly.
Product weight
190 g
Category
Bearings
Shipping calculated at checkout

Enter your delivery address at checkout to see the cost.

Subtotal: $11.66
Product specifications
Category
Bearings
Product weight
190 g
Width
16 mm
Internal Clearance
C3
Seal Type
Shielded 2 Sides
Outside Diameter (mm)
62
Dimensions (ID x OD x W)
30mm ID x 62mm OD x 16mm W
Bearing Type
Deep Groove Ball Bearing
Bore (mm)
30
