Bordo - 10x1.25mm Mf Bottoming HSS Tap | 3021-10.00B

Bordo – 10 x 1.25mm MF Bottoming HSS Tap | 3021-10.00B

The Bordo 10 x 1.25 mm MF Bottoming HSS Tap is a professional-grade Metric Fine (MF) bottoming threading tool engineered to produce full-depth, accurate internal threads — especially at the bottom of blind holes. Designed for workshop, fabrication and general industrial use, this tap is ideal where controlled thread engagement, minimal run-out and precision are critical.

Manufactured from high-speed steel (HSS) and engineered with a 60° thread angle, this bottoming tap features a flat thread crest and clearance at the root to promote excellent engagement between internal and external threads. The larger root radius and lower thread height improve chip flow and increase thread strength. Bottoming taps have a two-thread lead, allowing them to achieve minimal thread run-out when threading to the base of blind holes — and they are typically used after a taper or intermediate tap has started the thread. The 10 mm diameter and 1.25 mm pitch make this tap well-suited to threading fine pitch applications in medium tensile materials for either hand or general machine use.

Bordo is recognised in Australia for producing robust tooling backed by strong manufacturing standards. Industrial Shed ensures you have fast access to dependable trade-grade threading tools when you need them on site or in the workshop.

Product Type: Bottoming Tap
Brand: Bordo
Diameter: 10 mm
Pitch: 1.25 mm
Material: High-Speed Steel (HSS)
Thread Form: Metric Fine (MF)
Lead: Bottoming (two-thread lead)
Drill Diameter: 8.9 mm
Overall Length: 76 mm
Pack Quantity: 1
Part Number: 3021-10.00B
Application: Full-depth internal thread cutting in medium tensile materials for hand or general machine use

► Key Features

‣ 10 x 1.25 mm Metric Fine bottoming design for minimal thread run-out in blind holes
‣ Manufactured from durable high-speed steel for strength and wear resistance
‣ Flat thread crest with root clearance for smooth engagement and improved chip flow
‣ Two-thread lead helps achieve full-depth thread form after starting with taper or intermediate taps
‣ Suitable for hand or general machine use in workshop environments

► Why Tradies and Contractors Buy This

‣ Excellent for finishing threads to the base of blind holes
‣ Strong HSS build for durability on tough job sites
‣ Ideal for precision fabrication, maintenance and mechanical work
‣ Trusted Bordo quality and tooling standards
‣ Backed by Industrial Shed’s fast dispatch and trade support

► Stock won’t last — get yours now at Industrial Shed!
